34
EN
Fig. 26
A
Max
Min
4.3 ENGINE OIL (Version 250cc.)
Check the oil level every 3,000 km (1860 mi) or 6 months
• Place the scooter on a level surface on its centre stand. Start the
engine and wait until it reaches running temperature.
• Turn the engine off and wait for about 5 or 10 minutes, in order
to let the oil drain into the oil sump.
• Remove the cap and dipstick (A-Fig.26) from the engine cover
and clean it. Refit it and screw firmly down.
• Remove the cap with measuring rod again, and check that the
oil level is included between the min. and max. notches, as
shown in fig. 26.
• If the level is insufficient, top up with oil
• After topping up, screw the cap back on again.
• Total tank capacity: 1,000 cc.
• Recommended type of oil: Q8 CLASS 10W 40 / SBK RACING
15W 50
•
Should you check the oil level while the engine is warm, wait for
a few minutes in order to allow the engine to cool down.
NOTE
• When checking the oil level, make sure the vehicle is upright. A
slight tilting may alter the values.
• Filling to level, i.e. between the MIN. and MAX. level marks, me-
ans using around 400 cc of oil.
• Before topping up, check the oil level. Never fill to a level above
the MAX. mark.
