36
EN
Fig. 26a
Max
Min
A
ENGINE OIL (Version 125cc.)
Check the oil level every 1,000 km (930 mi) or 3 months
• Place the Scooter on the central stand and warm up the engine.
• Switch off the engine and wait a few minutes so that the oil level
can settle before checking.
• Unscrew and remove the dipstick (A - Fig. 26).
• Clean the dipstick and re-insert it in its seat without tightening it.
This allows you to check the oil level.
• The level has to be between the MIN. and MAX. notches on the
dipstick (Fig. 26). If the level is low, top-up with oil.
• Re-insert the dipstick and screw it into its seat.
• Max. oil quantity: 1400cc.
• Oil quantity for periodical change:
max 1300cc.
• Recommended oil: Q8 CLASS 10W-40.
Note: when you check the oil level, make sure that the vehicle is
upright. A slight lateral tilting may cause an incorrect value to be
indicated.
