Mamiya 645DF - ATTACHING AND REMOVING A LENS; Lens Attachment and Removal Steps; Post-Removal Lens Care and Cleaning

Chapter 1 - Basic info
35
removinG
Chapter 3 - Preparing the battery and compact flash card
attachinG and removinG a lens
2. Line up the lens mount alignment
mark with mark on the camera to
fit the lens in place, then rotate it in the
direction of the arrow until it
clicks into place.
While sliding the lens release button
back, rotate the lens counter clockwise
until it stops and lift it off.

Do not touch the distance ring or other rotating parts when attaching the lens.

When installing a lens, do not press the lens release button

After removing the lens from the camera body, protect both ends by attaching the caps.

Oil, dust, fingerprints or water on the electronic contacts could result in
malfunction or corrosion. Wipe such impurities off with a clean piece of cloth.
L
80mm
1:28
MF
AF
11
4
4
2
2
22
20
0
5
ft
m
C
B
8
0
m
m
1
:2
8
MF
A
F
11
11
4
4
2
2
22
20
0
5
A
