Man D2862 LE221 User Manual

COMMONRAILSYSTEM
Removingtherightpressurelimitingvalve
WARNING
Componentdamageduetolackof
lubricant
•Donotwashoffthepressurelimiting
valveasthethreadandbitingedgeare
coatedwithlubricant
Note
Theleftpressurelimitingvalveis
removedinthesamewayastheright
pressurelimitingvalve
•Unscrewthepressurelimitingvalve(1)
•RemovetheO-ring(2)fromthepressurelimiting
valve(1)
•PlugthepressurelimitingvalvewithProtective
sleeveZ18x15[12]andthethreadintherailwith
Endplug[11]
Removingtherightrailpressuresensor
WARNING
Componentdamageduetolackof
lubricant
•Donotwashofftherailpressuresensor
asthethreadandbitingedgeare
coatedwithlubricant
Note
Theleftrailpressuresensorisremoved
inthesamewayastherightrailpressure
sensor
•Unscrewtherailpressuresensor(1)
•PlugtherailpressuresensorwithProtective
sleeveZ18x15[12]andthethreadintherail
withEndplug[11]
Detachingtheholder
•Unscrewthemountingnut(1)
•Pulloutthemountingbolt(3)
•Positiontheholder(2)
AE63stedition111
