COMMONRAILSYSTEM
Removingthehigh-pressurelinesand
rails
Detachingthehigh-pressuresupplylines
WARNING
Dangerofdamageduetodirtingress
•Plugthecomponentconnections
immediatelyusingnew,clean
protectivesleeves
Note
High-pressurelinescanberemovedasa
setorindividually
•Marktheinstallationpositionofthepipeclamps
(2)and(4)
•Unscrewthepipeclampmountingbolts(2)and(4)
•Removetheclampingpieces(2)and(4)
•Detachthehigh-pressuresupplylines(1)and
(3)usingtheSpecialspanner,size17[40]in
conjunctionwiththeAngleextension[41]
•Plugthehigh-pressurelines(1)and(3)with
theEndplug[9]andtheconnectionswiththe
ProtectivesleeveZ14x15[10]
Detachingthehigh-pressureline
WARNING
Dangerofdamageduetodirtingress
•Plugthecomponentconnections
immediatelyusingnew,clean
protectivesleeves
Note
High-pressurelinescanberemovedasa
setorindividually
•Marktheinstallationpositionofthepipeclamps
•Removepipeclampsifrequired
•Unscrewtheunionnutsforthehigh-pressureline
(1)withtheAngleextension[15]andSpecial
spanner,size17[14]
•Unscrewtheunionnutsforthehigh-pressureline
(1)savefor2turns
•Unscrewtheunionnutsforthehigh-pressureline
(1)
•Removethehigh-pressureline(1)
•Plugthehigh-pressureline(1)withEndplug[9]
andtheconnectionswithProtectivesleeve
Z14x15[10]
•Repeatthesameprocedurefortheother
high-pressurelines
110AE63stedition
