COMMONRAILSYSTEM

Specialtools

[40]

Specialspanner,size17

•Detachingandattachingthehigh-pressurelinein

conjunctionwith:

•Angleextension[41]

80.99603-0309

[41] Angleextension

•Detachingandattachingthehigh-pressurelinein

conjunctionwith:

•Specialspanner,size17[40]

08.06139-9025

[42] Endplug

•Pluggingthehigh-pressurelines

81.96002-0521

[43] ProtectivesleeveZ14x15

•Pluggingthehigh-pressurelineconnections

81.96002-0512
