COMMONRAILSYSTEM
Removingthehigh-pressurepump
Detachingthehigh-pressuresupplylines
•Marktheinstallationpositionofthepipeclamps
(2)and(4)
•Unscrewthepipeclampmountingbolts(2)and(4)
•Removepipeclamps(2)and(4)
•Detachthehigh-pressuresupplylines(1)and
(3)usingtheSpecialspanner,size17[40]in
conjunctionwiththeAngleextension[41]
•Plugthehigh-pressurelines(1)and(3)with
theEndplug[42]andtheconnectionswiththe
ProtectivesleeveZ14x15[43]
Removingtheslavehigh-pressurepump
•Disconnectthemeteringunitelectricalconnection
•Removethedriversleeve(3)
•Unclipthecirclip(4)andremoveit
•Unscrewthemountingbolts(6)
•Removethehigh-pressurepump(1)
•RemovetheO-rings(2)and(5)
•Cleanthesealingsurfaces
Detachingthecover
•Unscrewthemountingbolts(2)
•Removethecover(3)withtheseal(1)
•Cleanthesealingsurfaces
Detachingthecover
•Unscrewthemountingbolts(1)
•Removethecover(2)withtheseal(3)
•Cleanthesealingsurfaces
Unscrewingthehigh-pressurepumpmounting
bolts
•Unscrewthemountingbolts(1)
132AE63stedition
