Man D2862 LE221 - Injector Procedures

COMMONRAILSYSTEM
Installingtherightrailpressuresensor
WARNING
Componentdamageduetolackof
lubricant
•Donotwashoffthepressurelimiting
valveandrailpressuresensorasthe
threadandbitingedgearecoatedwith
lubricant
Note
Theleftrailpressuresensorisinstalled
inthesamewayastherightrailpressure
sensor
•Removethecapsandplugs
•Screwintherailpressuresensor(1)andtightenit
to80Nm
Installingtherightpressurelimitingvalve
WARNING
Componentdamageduetolackof
lubricant
•Donotwashoffthepressurelimiting
valveandrailpressuresensorasthe
threadandbitingedgearecoatedwith
lubricant
Note
Theleftpressurelimitingvalveisinstalled
inthesamewayastherightpressure
limitingvalve
•Removethecapsandplugs
•PullthenewO-ring(2)ontothepressurelimiting
valve(1)
•Screwinthepressurelimitingvalve(1)andtighten
to100Nm
