COMMONRAILSYSTEM
WARNING
Componentdamageduetoreusedbolts
•Donotre-useapressureangemountingbolt,evenifithasonlybeenusedonce.
Note
Inordertoensurethatthecorrectprotectivesleeveisused,thedesignation(e.g.Z14x15)is
imprintedintheprotectivesleeves.Thisisintegratedinthespecialtooldesignation(e.g.protective
sleeve,high-pressurelineconnectionZ14x15).
Specialtools
[16]
Storagesleeve
•Storinginjectors
09.81020-1000
[17] Endplug
•Pluggingthecylinderheadinjectorbore
81.96002-0520
[18] Injectornozzleprotectivesleeve
•Pluggingtheinjectornozzle
81.96002-0522
[19]
Injectorfeedborecap
•Pluggingtheinjectorfeedbore
81.96002-0523
[20] Endplug
•Pluggingtheboreforrailconnections
81.96002-0541
[21] Extractor
•Extractingtheinjectorinconjunctionwith:
•Plate[22]
•Support[23]
•Hexagoncollarnut[24]
80.99601-6022
AE63stedition117
