Man D2862 LE221 - Page 145

To Next Page

To Previous Page

COMMONRAILSYSTEM

[49] ProtectivesleeveZ18x1.5

•Pluggingthefuellineconnections

81.96002-0555

[50] ProtectivesleeveZ16x8

•Pluggingthefuellineconnections

81.96002-0513

[51] ProtectivesleeveZ28x20

•Pluggingtheconnectiononthecollector

81.96002-0514

[52]

Cap

•Pluggingtheringunions

81.96002-0518
