COMMONRAILSYSTEM
Detachingthefuellinefuellter–high-pressure
pumpbottom
•Unscrewtheunionnuts(1)and(3)
•Removethefuelline(2)
•Plugthefuelline(2)withtheEndplug(GPN330
L18)[46]
•PlugtheconnectionswithProtectivesleeveZ
18x1.5[49]
Detachingthefuellinerightrail–collector
•Unscrewthehollowscrews(1)and(3)andremove
themwiththesealingrings
•Removethefuelline(2)withsealingrings
•Plugthefuelline(2)withtheCap[52]
•PlugtheconnectionswiththeEndplug[48]
Detachingthefuellinehandpump–
high-pressurepumpbottom
•Unscrewtheunionnuts(1)and(3)
•Removethefuelline(2)
•Plugthefuelline(2)withtheEndplug(GPN330
L18)[46]
•PlugtheconnectionswithProtectivesleeveZ
18x1.5[49]
Detachingthefuellinerail–collector
•Unscrewtheunionnut(1)
•Unscrewthehollowscrew(3)andremoveitwith
thesealingring
•Removethefuelline(2)
•Plugthefuelline(2)withtheCap[52]andEnd
plug[47]
•PlugtheconnectionswithProtectivesleeveZ
16x8[50]andEndplug[48]
AE63stedition147
