COMMONRAILSYSTEM
Removingthefuellter
Detachingthefuellinegearpump–fuellter
•Unscrewthemountingnut(2)
•Pulloutthemountingbolt(1)
•Unscrewtheunionnuts(3)and(5)
•Removethefuelline(4)
•Plugthefuelline(4)withtheEndplug(GPN330
L18)[53]
•PlugtheconnectionwithProtectivesleeveZ
28x20[56]
Detachingthefuellinefuellter–high-pressure
pumps
•Unscrewtheunionnuts(2)and(5)
•Removethefuelline(4)
•Plugthefuelline(4)withtheEndplug(GPN330
L18)[53]
•PlugtheconnectionwithProtectivesleeveZ
28x20[56]
Detachingthefuelreturnline
•Unscrewthemountingnut(6)
•Pulloutthemountingbolt(1)
•Unscrewthemountingnut(4)
•Pulloutthemountingbolt(2)andremovetogether
withbush(3)
•Removethefuelline(5)
•Plugthefuelline(5)withtheEndplug(GPN330
L18)[53]
Detachingthefuellter
•Unscrewthemountingbolts(1)
•Removethefuellters(2),(3),(4)and(5)
AE63stedition157
