INTAKE/EXHAUSTSYSTEM
Removingthecombinationairlter
holder
Detachtheventline
•Removethejubileeclips(1)and(3)usingtheHose
clamppliersforjubileeclips[63]
•Releaseholdingclips(4)and(5)
•Removetheventline(2)
•Repeatthesameprocedurefortheotherventline
Detachingcorrugatedpipes
•Unclipcorrugatedpipes(1)and(3)fromthe
corrugatedpipeholders(2)and(4)
Detachingtheholderfortheinjectorwiring
harness
•Unscrewthemountingnuts(3)
•Removetheinjectorwiringharnessholder(1)with
spacerbush(2)
•Repeattheprocedurefortheotherholder
Detachingthecombinationairlterholder
•Unscrewthemountingbolts(2)
•Removethecombinationairlterholder(1)
•Repeattheprocedurefortheotherholder
Detachingthecarrier
•Unscrewthemountingbolts(2)
•Removethesupport(1)
•Repeatthesameprocedureforothersupports
194AE63stedition
