Man D2862 LE221 - Air Distribution Pipes Procedures

INTAKE/EXHAUSTSYSTEM
Installingthecombinationairlter
holder
Attachingthecarrier
•Positionthecarrier(1)
•Screwinandtightenthemountingbolts(2)
•Repeatthesameprocedureforothersupports
Attachingthecombinationairlterholder
•Positionthecombinationairlterholder(1)
•Screwinandtightenthemountingbolts(2)
•Repeattheprocedurefortheotherholder
Attachingtheholderfortheinjectorwiring
harness
•Positiontheinjectorwiringharnessholder(1)with
spacerbush(2)
•Screwinandtightenthemountingnuts(3)
•Repeattheprocedurefortheotherholder
Attachingcorrugatedpipes
•Clipcorrugatedpipes(1)and(3)intothe
corrugatedpipeholders(2)and(4)
AE63stedition195
