CYLINDERHEAD
Finaltighteningofcylinderheadbolts
Note
Notethetorquemultiplierratio,i=1:3.3.
•Tightenthecylinderheadboltsto4thtorque90°,
inthetighteningsequence,withspecialtool(1)
•Tightenthecylinderheadboltsto5thtorque90°,
inthetighteningsequence,withspecialtool(1)
•TightenthecylinderheadboltstoFinaltightening
90°,inthetighteningsequence,withspecialtool
(1)
•Disassemblethespecialtool(1)
•RemoveAligningbar[78]
Attachingthecranehooklugsontheleftand
right
•Positionthecranehooklug(2)
•Screwinandtightenthemountingbolts(1)
•Positionthecranehooklug(4)
•Screwinandtightenthemountingbolts(3)
