CYLINDERHEAD
Adjustingtheintakevalveclearance
•Unscrewthelocknut(4)
•Unscrewtheadjustingscrew(5)untilthe(1)with
(2)canbeinsertedbetweentheballsocket(6)and
thevalvebridge(3)
•Screwintheadjustingscrew(5)untilthe(1)with
(2)canbemovedbetweentheballsocket(6)and
thevalvebridge(3)withlittleresistance(suction)
•Holdtheadjustingscrew(5)steadywithValve
wrenchsize14[97]
•Holdtheadjustingscrew(5)steadyandtighten
thelocknut(4)to45Nm
•Checkthesettingoncemore
Checkingtheexhaustvalveclearance
•Insertthe(1)with(2)betweenthevalvebridge(3)
andtheballsocket(4)
Adjustthevalveclearanceifthevalveclearanceis
not0.80mm
Settingtheexhaustvalveclearance
•Unscrewthelocknut(4)
•Unscrewtheadjustingscrew(5)untilthe(1)with
(2)canbeinsertedbetweentheballsocket(6)and
thevalvebridge(3)
•Screwintheadjustingscrew(5)untilthe(1)with
(2)canbemovedbetweentheballsocket(6)and
thevalvebridge(3)withlittleresistance(suction)
•Holdtheadjustingscrew(5)steadywithValve
wrenchsize14[97]
•Holdtheadjustingscrew(5)steadyandtighten
thelocknut(4)to45Nm
•Checkthesettingoncemore
Attachingthecylinderheadcover
•Fitthecylinderheadcover(1)
•Screwinandtightenthemountingbolts(2)
AE63stedition241
