VALVETIMING
(1)Camshaft
(2)Camshaftgear
(3)Mountingbolt
(4)Anti-rotationdevice
(5)Rollertappet
Camshafttechnicaldata
Anti-rotationlock.............................................................................................................................22Nm
Mountingbolt,oilinjectornozzle............................M14x20-10.9....................................................120Nm
Axialplay,camshaft......................................................................................................0.100–0.250mm
Radialplay,camshaft.....................................................................................................0.060–0.112mm
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
Specialtools
[99]
Insertionpin
•Removing,installingthecamshaft
80.99617-6009
246AE63stedition
