VALVETIMING

Specialtools

[100]

Enginebarringgear

•Crankingtheengineinconjunctionwith:

•Gearratchet[101]

80.99626-6009

[101]

Gearratchet

•Crankingtheengineinconjunctionwith:

•Enginebarringgear[100]

80.99627-0001

[102] Dialgaugeholder

•Checkingthevalvetiminginconjunctionwith:

•Dialgauge[103]

08.71082-0005

[103] Dialgauge

•Checkingthevalvetiminginconjunctionwith:

•Dialgaugeholder[102]

08.71000-3217

252AE63stedition
