FRONTTIMINGGEARS/REARTIMINGGEARS
Installingthereartiminggears
Installingthecrankshaftgear
•ScrewintheAligningtool[105](2)and(3)
•Aligntheboreinthecrankshaftgear(1)withthe
centringpin
•Pushthecrankshaftgear(1)ontothecrankshaft
•UnscrewtheAligningtool[105](2)and(3)
Checkingthecrankshaftgearmark
•Checkthatthemark(1)andmark(2)matchup
Ifthemarks(1)and(2)donotmatchup,removethe
crankshaftgearandre-insertitatthemark.
