CRANKMECHANISM
Installingtheywheel
Puttingontheywheel
CAUTION
Dangerofinjuryduetoheavy
components
•Useliftinggeartoinstalltheywheel
WARNING
Componentdamageduetoreused
ywheelbolts
•Fitnewmountingboltsiftheexisting
oneshavebeenunscrewed
•Alignthedowelholeintheywheel(3)withthe
crankshaftalignmentpin
•Putontheywheel(3)overtheAligningtool[126]
(1)and(2)
Unscrewingthealigningtools
•Screwinthenewywheelmountingbolts
•UnscrewtheAligningtool[126](1)and(2)
Screwingintheywheelmountingbolts
•Screwintheremainingnewmountingbolts(1)and
(2)
Tighteningdiagram
•Tightenthemountingboltsinthesequence1-10
AE63stedition321
