CRANKMECHANISM

Tighteningtheywheelmountingbolts

Note

Notethetorquemultiplierratio,i=1:3.3.

•Tightenthemountingbolts(1)toInitial

torque100Nmasperthetighteningdiagram

•Tightenthemountingbolts(1)usingthespecial

tool(2)inconjunctionwiththeSocket[132]

•Tightenthemountingbolts(1)toSecond

tightening90°asperthetighteningdiagram

•Tightenthemountingbolts(1)toFinaltightening

90°asperthetighteningdiagram
