CRANKCASE

Importantinformation

WARNING

Componentdamageduetoincorrectlytightenedscrew/boltconnections

•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe

speciedtighteningtorque

•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench

Specialtools

[167]

Aligningtool

•Removing,installingthefrontcrankshaftgear

80.99617-0020

360AE63stedition
