CRANKCASE
Removingtheywheelhousing
Detachingtheywheelhousing
CAUTION
Dangerofinjuryduetoheavy
components
Useliftinggeartoremovetheywheel
housing
Marktheinstallationpositionofthemountingbolts
(1)and(3)
Marktheinstallationpositionofthemountingbolts
(1)and(3)andunscrew
Removetheywheelhousing(2)withseal(4)
Cleanthesealingsurfaces
Dismantlingtheywheelhousing
Unscrewthemountingbolts(5)
Removethecranehook(1)
Unscrewthescrewplugs(2),(3)and(4)and
removewithsealingrings
Cleanthesealingsurfaces
Dismantlingtheywheelhousing
Unscrewthescrewplug(2)andremovewith
sealingring(3)
Unscrewthemountingbolts(5)
Removethecover(6)withtheseal(7)
Unscrewthemountingbolts(8)andremovethe
washers(1)andadjustingplate(4)
Cleanthesealingsurfaces
AE63stedition365
