CRANKCASE

[174] Washer

•Checkingthecylinderlinerstandoutin

conjunctionwith:

•Dialgaugeholder[170]

•Dialgauge[171]

•Measuringplate[172]

•Bolt[173]

06.15013-0417

[175]

Depthgauge(electronic)

•Checkingthecylinderlinerseating

08.71195-9003

370AE63stedition
