CRANKCASE
Removingthecylinderliner
Fittingtheextractordevice
WARNING
Componentdamageduetodamaged
orbentoilinjectornozzles
•InserttheExtractordevice[168]without
damagingtheoilinjectornozzle
•Marktheinstallationorientationandinstallation
positionofthecylinderliner(2)ifitistobereused
•AttachtheExtractorplate[169](1)ontheExtractor
device[168](3)
•CarefullypushtheExtractordevice[168](3)with
foldedExtractorplate[169](1)intothecylinder
liner(2)
Extractingthecylinderliner
•ClamptheExtractordevice[168](1)withthe
hexagonnut(2)
•Extractthecylinderliner(3)byscrewinginthe
hexagonnut(2)
Removingthesectionalsealingrings
•Removethesectionalsealingrings(1)and(2)
fromthecrankcase
•Cleanthecylinderlinerseatandsectionalsealing
ringseats
•Checkthesectionalsealingringseatsonthe
cylinderlinerforwear
•Checkthecylinderlinersforporosity
AE63stedition371
