COOLINGSYSTEM
Removingthecoolingsystem
Detachingtheradiatorstruts
•Marktheinstallationpositionoftheradiatorstruts
(2)
•Unscrewthemountingbolts(1)
•Removetheradiatorstruts(2)
Detachingtherightchargeairhose
•Unfastenhoseclamps(1)and(3)
•Removethebellowshose(2)withhoseclamps(1)
and(3)
•Unfastenthehoseclamp(6)
•Removethechargeairmanifold(4)withO-ring(5)
andhoseclamp(6)
Detachingtherightmouldedhose
•Unfastenhoseclamps(1)and(3)
•Removethemouldedhose(2)withhoseclamps
(1)and(3)
Detachingtheleftchargeairhose
•Unfastenhoseclamps(4)and(6)
•Removethebellowshose(5)withhoseclamps(4)
and(6)
•Unfastenthehoseclamp(2)
•Removethechargeairmanifold(3)withO-ring(1)
andhoseclamp(2)
