Manitou TMT 25 I K ST5 S1 User Manual

SAFETY PLATES AND STICKERS

IMPORTANT

Clean all stickers and safety plates so that they are legible. Any safety plates and stickers which are illegible or damaged must be replaced. Check that stickers and safety
plates are present after replacing any spare parts.
ITEM PART NO. DESCRIPTION
1
24653 - Slinging point
2
275329 - Crushing hazard TMT .. S ...
3
293887 - Anti-freeze
4
52664861 - Air filter cartridge
5
524814 - Triangular reflector
6
293791 - Reflective sticker
7
234798 - Hydraulic oil
8
234802 - Diesel fuel
9
239594 - Sound power level 104dB
10
234806 - Differential lock
11
52639409 - MANITOU QR code
12
733846 - Steering mode TMT ... 4W ...
13
255934 - Safety instruction
14
300681 - Instructions prior to start-up
15
574317 - Unladen travel safety instruction
16
301069 - Load chart TMT 25 I ...
17
301074 - Load chart on tires TMT 25 S ... / TMT 25 S 4W ...
18
301072 - Load chart on stabilizers TMT 25 S ... / TMT 25 S 4W ...
19
301100 - Load chart on tires TMT 27 S ...
20
301101 - Load chart on stabilizers TMT 27 S ...
21
301075 - Load chart TMT 27 P ... (CoG 500mm)
22
301129 - Load chart TMT 27 P ... (CoG 1,200mm)
23
721744 - Manipulator function
24
76571 - Forward/reverse selector
