Manitou TMT 25 I K ST5 S1 User Manual

F+E1-HYDRAULIC ATTACHMENT OPTION
F+E2-HYDRAULIC ATTACHMENT OPTION
NOTE: Press button F to activate or deactivate the additional hydraulic attachment.
The green lamp F1 indicates that it is in use.
14 - HYDRAULIC CONTROLS

IMPORTANT

Do not try to modify the hydraulic pressure of the system. If it malfunctions contact your dealer.
ANY MODIFICATION INVALIDATES THE WARRANTY AND YOU WILL BE CRIMINALLY LIABLE IN THE EVENT OF AN ACCIDENT.
Use the hydraulic controls gently without jerking to avoid incidents caused by shaking the machine.
A1-LIFTING
A2-LOWERING
B1-TELESCOPE EXTENSION
B2-TELESCOPE RETRACTION
C1-CROWD
C2-DUMP
D1-SIDEWAYS BOOM MOVEMENT TO THE RIGHT
D2-SIDEWAYS BOOM MOVEMENT TO THE LEFT
E1-STABILIZER LOWERING
E2-STABILIZER LIFTING
2 - 41
A2
A1
B2
B1
C2
C1
D2
D1
E2
E1
F
E2
E1
F1
647866 M1 (A012021) TMT ... K ST5 S1
