DESCRIPTION (standard)
2 - DRIVER'S SEAT
DESIGNED FOR MAXIMUM COMFORT, THIS SEAT CAN BE ADJUSTED AS FOLLOWS.
LONGITUDINAL ADJUSTMENT
- Pull the locking lever 1 upwards.
- Slide the seat assembly to achieve the desire driving position.
- Release the lever and be sure it returns to the lock position.
SEAT SUSPENSION ADJUSTMENT
- Turn control knob 2 to set the desired suspension.
BACKREST ANGLE ADJUSTMENT
- Turn knob 3 to tilt the backrest to the desired position.
MAINTENANCE
Dirt may adversely affect the correct functioning of the seat. Make sure that it is clean.
- First test the resistance of the coating on a hidden area with a textile cleaner.
NOTE: As an option, a protective transport case is available.
1 - DRIVER'S CAB ACCESS
- Getting into and out of the driver's cab.
- Use the three support points provided.
• A-Left handle.
• B-Right handle or steering wheel.
• C-Driver's cab step.
3 - SEAT BELT
- Sit down correctly in the seat.
- Check the condition of the seat belt.
- Place the seat belt at hip level, without twisting it.
- Lock the seat belt.
NOTE: The machine cannot be moved if the seat belt is not correctly done up. A
warning appears on the screen (
SCREEN - "WARNINGS AND FAULTS" PAGE
- C1 - MOVEMENT WARNINGS).
2 - 26
3
1
2
2
B
C
A
B
1
647866 M1 (A012021)
TMT ... K ST5 S1
