SPECIFICATIONS TMT 25 I K ST5 S1
DESIGNATION
1.1 Manufacturer MANITOU
1.2 Model type TMT 25 I K ST5 S1
1.3 Propulsion: battery, diesel, petrol, LPG, mains Diesel
1.4 Type of operation: manual, pedestrian, standing, seated Seated
1.5 Rated capacity / load on forks (basic capacity) Q (t) 2,5
1.6 Load center of gravity c (mm) 500
1.8 Distance from the load bearing surface to the center of the front axle x (mm) -505
1.9 Wheelbase y (mm) 1784
WEIGHT
2.1 Weight of machine in working order kg
2.2 Load on front axle, machine laden kg
2.2.1 Load on rear axle, machine laden kg
2.3 Load on front axle, machine unladen kg
2.3.1 Load on rear axle, machine unladen kg
RUNNING GEAR
3.1 Tire equipment: bandage (V), super-elastic (SE), pneumatic (L) L
3.2 Tire size, front " / mm 18x7-8
3.3 Size of rear wheels " / mm 10x16,5
3.5 Number of front wheels (x = drive wheel) 2x
3.5.1 Number of rear wheels (x = drive wheel) 1x
3.6 Front wheel gage (middle of wheels) b10 (mm) 2102
3.7 Rear wheel gage (middle of wheels) b11 (mm) 0
DIMENSIONS
4.1 Forward tilt of carriage α(°) 100
4.1.1 Backward tilt of carriage β (°) 12
4.2 Height mast lowered h1 (mm) 2285
4.3 Free lift, normal h2 (mm) 1700
4.4 Lift height h3 (mm) 3380
4.5 Height mast extended h4 (mm) 3925
4.7 Height of standard or cab driver protection h6 (mm) 2200
4.7 Height of lowered driver protection (OPTION) h6* (mm) 2000
4.8 Height of seat h7 (mm) 1220
4.19 Overall length l1 (mm) 2790
4.20 Length of forks at heel l2 (mm) 1590
4.21 Overall width b1 (mm) 2455
4.22 Thickness of fork arms s (mm) 40
4.22.1 Width of forks e (mm) 125
4.22.2 Length of forks l (mm) 1200
4.23 Fork carriage (standard
DIN 15173 A/B) FEM 2A
4.24 Width of fork carriage b3 (mm) 1270
4.25 Distance between forks b5 (mm) 1267
4.26 Distance between wheel stubs b4 (mm) 1634
4.32 Ground clearance at center of wheelbase m2 (mm) 278
4.33 Aisle width for 1000x1200 pallet widthwise Ast (mm) 3970
4.34 Aisle width for 800x1200 pallet lengthwise Ast (mm) 3970
4.35 Turning radius Wa (mm) 3011
4.36 Inner turning radius b13 (mm) 269
2 - 10
647866 M1 (A012021) TMT ... K ST5 S1
