OPERATING CONTROLS AND PROCEDURES 18000 OPERATOR MANUAL
3-50
Published 12-05-17, Control # 032-23
Table 3-4 Operating Conditions
Listed below are the operating conditions which can be viewed on the digital display.
[1] Optional Item
[2] Appropriate Drum Number (see Figure 3-10
)
Display Reading
Unit of
Measure
Operating Range
Normal Operating Conditions
The operating conditions listed below are displayed by scrolling up or down with the digital display selector.
ENGINE SPEED RPM 1,050 RPM low idle; 1,800 RPM high idle.
BOOM ANGLE DEG Degrees boom is positioned above horizontal.
LUFFING JIB ANGLE [1] DEG Degrees luffing jib is positioned above horizontal.
BOOM TO LUFF ANGLE [1] DEG Degrees between centerline of boom and centerline of luffing jib.
FUEL LEVEL % Indicates 0-100% of fuel remaining in tank.
OIL PRESSURE PSI Indicates engine oil pressure when operating.
COOLANT TEMP DEG F Indicates temperature of coolant in engine.
ENGINE HOURS HOURS Indicates total number of hours the engine has been run.
ENGINE DIAGNOSTICS — Indicates engine fault codes and engine troubleshooting.
MAST ANGLE DEG Degrees live mast is positioned above transport position, which is 0°
BATTERY VOLTAGE V Indicates crane battery voltage.
TILT RIGHT (Crane Level)
TILT FRONT (Crane Level)
DEG/IN Angle (+ or - degrees) that crane is out of level in indicated direction from
horizontal.
HYD TANK FLUID LEVEL % Indicates hydraulic tank fluid level in % full.
CURRENT WIND SPEED MPH Indicates current steady wind speed.
(MAX) WIND SPEED MPH Indicates maximum gust wind speed.
PUMP DRIVE TEMP DEG F Indicates temperature of oil in pump drive.
PUMP DRIVE PRESSURE PSI Indicates pump drive oil pressure when operating.
Diagnostic Screens
Operating conditions listed below are displayed only by turning limit bypass switch and scrolling up with digital display
selector. To turn off diagnostic screens, turn limit bypass switch and scroll down or stop and restart engine.
DRUM [2]
4 Rows of
Text and
Numbers
in Display
Screen
Text and numbers are used to monitor and troubleshoot controls and hydraulic
systems. See Crane Diagnostics in this section for explanation of these
screens.
SWING
TRK (Travel)
FCN (Front Console Node)
CAN (CAN-Bus)
ACC (Accessory System)
WIRELESS
LEVEL
SPEEDS AND TORQUE
HYD SYSTEM CHECK
CRANE MODE
(name of mode)
— See Crane Mode Selector instructions in this section for procedure to select
and confirm desired crane mode.
PROGRAM M000001.0JP — Computer Program Version. Factory service personnel will request these
numbers when troubleshooting crane problems.
CON 00000000000 — Computer and Crane Configuration Code. Factory service personnel will
request these numbers when troubleshooting crane problems.
