OPERATING CONTROLS AND PROCEDURES 18000 OPERATOR MANUAL
3-52
Published 12-05-17, Control # 032-23
[1] Optional item
[2] Angle at which boom stops varies with attachment. See Max Up 1 (boom) table in this section for specifications.
SWING PARKED
(cranes with swing lock)
Stops travel function with MAX-ER. Place swing park in off position to travel.
SWING PARKED
(cranes without swing lock )
Stops travel function without MAX-ER. 1) Place swing park in off position to travel.
2) Install W48 Shorting Plug in MAX-ER
Junction Box IF configured without MAX-ER
attachment. 3) Confirm swing brake release
pressure on Swing (Crane) diagnostic
screen; if below 200 psi, troubleshoot swing
brake hydraulic circuit.
Display Reading Function Response Corrective Action
