18000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
FIGURE 4-13
3
View A
2
View B
Align This Edge with
Front and Rear or Carbody
Lift Here
with Forks
4
P1963
4-113
1
Item Description
1 Carbody
2 Carbody Pedestal
3 Carbody Pedestal Support Pad
4 Pedestal Adjustment Screw
5 Rear Rotating Bed Jack
6 Front Rotating Bed Jack (stored)
7 Lifting Hole (2 places)
8 Drum 3 (Whip Line)
9Fixed Pin
10 Pin with Cotter Pins
6
Stored
View D
5
4-114
View C
10
P1933a
9
8
7
