Manitowoc Published 12-05-17, Control # 032-23 4-129
18000 OPERATOR MANUAL SET-UP AND INSTALLATION
4
Item Description Item Description
1 Pin with Cotter Pin 7 Swivel (25 USt)
2 Link 8 Button Socket – 1-1/8 in (28 mm) or 1-1/4 in (32 mm)
Wire Rope with Pin
3 Pin with Cotter Pin 9 Wedge Socket – 1-1/8 in (28 mm)
4 Load Cell - 70,000 lb (31 751 kg) 10 Link
5 Link 11 Pin with Cotter Pin
6 Pin with Cotter Pin 12 Swivel Weight Ball
1
2
3
4
9
1
2
4
8
6
7
5
3
6
7
5
FIGURE 4-75
STANDARD UPPER BOOM POINT A08516
12
9
3
4
2
1
9
10
4
10
4
2
1
3
8
1
2
11
2-Part
1-1/8 in (28 mm)
Wire Rope
1-Part
1-1/8 in (28 mm)
Wire Rope
2-Part
1-1/4 in (32 mm)
Wire Rope
STANDARD UPPER BOOM (JIB) POINT 170419
4-216
4-217
4-218
4-2204-219
8 OR 9
10
4
11
11
1
2
12
2-Part
1-1/4 in (32 mm) Wire Rope
OR
1-1/8 in (28 mm) Wire Rope
2-Part
1-1/8 in (28 mm)
Wire Rope
1-Part
1-1/4 in (32 mm) Wire Rope
OR
1-1/8 in (28 mm) Wire Rope
