Swing-away lattice
3.4 Description of the rigging work
3 - 62 3 112 441 en Lattice extension operating instructions
GMK 4100/4100-L/5095
11.01.2008
Disconnecting the electrical connection
• Remove the plug (4) from the socket (1) and
plug it into the dummy socket (6).
• Wind the cable (5) onto the holder (7).
• Remove the bridging plug (3) from the
dummy socket (2) and plug it into the
socket (1).
