Swing-away lattice
3.3 Rigging work checklists
Lattice extension operating instructions 3 112 441 en 3 - 7
GMK 4100/4100-L/5095
11.01.2008
3.3 Rigging work checklists
3.3.1 Overview of the required rigging work
There are different initial conditions for rigging the swing-away lattice,
depending on whether the swing-away lattice is:
– Folded on the side of the main boom or
– Removed for on-road driving.
You can find out which checklist describes the required rigging work for
your initial condition in the following table.
1)
Details on the driving mode à Operating instructions GMK 4100/4100-L/
5095 – driving modes
.
Initial condition of the
swing-away lattice
Corresponding
checklist for ...
Before
crane oper-
ation
– On the side of the main
boom
à Rigging; p. 3 - 15
– Completely removed
à Installation; p. 3 - 8
After crane
operation
– To be folded on the side of
the main boom
à Unrigging; p. 3 - 21
– To be removed for on-
road driving
à Removal
1)
; p. 3 - 10
