For operations planning
2.1 Notes
Lattice extension operating instructions 3 112 441 en 2 - 1
GMK 4100/4100-L/5095
11.01.2008
2 For operations planning
2.1 Notes
The following section contains information on the following subjects:
– Assembly
– Identification
– Transport dimensions and weights
– Slinging points
– Transport
Assembly The length dimensions correspond to the respective distances between the
centre of the locking pin (on the main boom head) and the front edge of the
head sheave.
Therefore, the length dimensions of the individual parts from
Transport dimen-
sions and weights
and their sum do not agree with the lengths specified there.
Identification
Transport dimen-
sions and weights
Observe the weight specifications and the dimensions of the lattice exten-
sions in the respective sections. The dimensions specified here and their
sums do not correspond to the specifications in the section titled
Assembly.
s
S
Risk of accidents if not adjusted properly
The lattice extension is designed for the truck crane with which it was
delivered.
If a lattice extension is to be used on several truck cranes, it must be
adjusted to the truck crane and marked with the serial number.
Have the lattice extensions only adjusted by
CraneCARE.
You can prevent malfunctions and damage in this way.
