Maintenance work on the carrier
7.10 Wheels
09.03.2018
Maintenance manual 3 302 746 en 7 - 75
GMK5200-1
7.10.3 Checking that the wheel nuts are tight
Spare parts and
tools
– Torque wrench for 650 Nm (480 lbf ft).
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Checking the
wheel nuts
• Check the wheel nuts and the pressure
plates for damage.
• Replace any damaged wheel nuts or pres-
sure plates.
• Check the wheel nuts in sequence (1-12) for
a tight fit – torque 650 Nm (480 lbf ft).
Designation Quantity
per wheel
GROVE part no.
Wheel nut with pressure plate
for steel rims
12 01207756
Wheel nut with pressure plate
for aluminium rims
12 7659100000
