Maintenance work on the superstructure
8.4 Slewing gear
09.03.2018
Maintenance manual 3 302 746 en 8 - 15
GMK5200-1
8.4 Slewing gear
8.4.1 Checking the oil level
Spare parts and
tools
Prerequisites – The truck crane must be level and in on-road mode; à Operating manual.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Checking the oil
level
Always check the oil level prior to using the crane.
• Check that oil is visible in the inspection
glass (1).
• Always check the oil level for all the slewing
gears.
If the oil level is too low
• Top up the oil; à p. 8 - 19.
Designation Quantity GROVE part no.
Gasket 10 x 14 Cu DIN 7603 3 00117125
