Maintenance work on the superstructure
8.8 Hoist ropes
8 - 62 3 302 746 en Maintenance manual
GMK5200-1
09.03.2018
8.8.5 Replacing the hoist rope
Spare parts and
tools
– An authentic replacement rope; à Rope certificate.
– A reel stand with braking block.
– Torque wrench for 78 Nm (57.5 lbf ft).
Prerequisites – The truck crane must be level.
– The main boom must be set down on the boom rest.
– The hook block must be unreeved; à Operating manual.
Replacing the old
rope
• Unreel the hoist rope until it switches off.
• Adjust the lowering limit switch so that you can unreel the rope com-
pletely;
à Setting the lowering limit switch, p. 8 - 65.
• Unreel the remaining layers from the hoist drum.
• Protect the truck crane from unauthorised use; à p. 2 - 3.
S
Risk of accidents from falling load.
Use only a replacement rope that has the same technical specifications as
the defective rope, or an authentic replacement rope.
G
Risk of accidents due to the rotating rope drum.
Turn off the engine and remove the ignition key so that no unauthorised
operation of the hoist can occur.
