Manitowoc Grove GMK 5200-1

Maintenance work on the carrier
7.3 Engine
09.03.2018
Maintenance manual 3 302 746 en 7 - 15
GMK5200-1
7.3.4 Checking the air filter
• Start the engine and observe the display.
• If the symbol (1) is displayed, you must change the air filter.
• Switch off the engine.
Spare parts and
tools
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Replacing the air
filter
• Undo all the clamps (1) and remove the
cover (2).
• Change the filters (3) and (4).
• Replace the cover and secure it with all the
clamps.
D
Designation Quantity GROVE part no.
Main filter 1 04161948
Back-up filter 1 04161949
