Manitowoc Grove GMK 5200-1

Maintenance work on the superstructure
8.14 Other maintenance work
09.03.2018
Maintenance manual 3 302 746 en 8 - 81
GMK5200-1
8.14 Other maintenance work
8.14.1 Checking the windscreen washing system
Water, spare
parts, tool
– Water; add commercially available detergent and antifreeze to it.
– A can for mixing and filling.
Prerequisites – The crane cab door is pushed back – the filler neck with the cap (1) is
accessible.
Topping up
If the tank is empty
• Open the cap (1) on the filler neck.
• Top up the windscreen washing fluid
through the filler neck.
• Close the filler neck with the cap.
s
W
Designation Quantity GROVE part no.
Windscreen wiper blade 1 03268512
Roof wiper blade 1 03326121
