Lubricants and consumables
6.1 Lubricants
09.03.2018
Maintenance manual 3 302 746 en 6 - 3
GMK5200-1
6.1.2 Lubricant applications list
Serial
no.
Lubricant type Usage Filling
quantity in
litres (gal)
Mainten-
ance inter-
val
1 Engine oil Diesel engine; à p. 7 - 24 39 (10.3) Y 2
2 Gear oil VIAB (Voith); à p. 7 - 43 11 (2.9) Y 3
3 Gear oil Transmission; à p. 7 - 46 17.5 (4.6) Y 3
4 Gear oil
3
er
axle line transfer case
for drive 10 x 6;
à p. 7 - 50
12.8 (3.4) M 6
3
er
axle line transfer case
for drive 10 x 8;
à p. 7 - 50
14 (3.7) M 6
3
er
axle line axle centre drive; à p. 7 - 63 14 (3.7) M 12
2
nd
axle line axle centre drive; à p. 7 - 63 13.0 (3.5) M 12
5
th
axle line axle centre drive; à p. 7 - 63 13.0 (3.5) M 12
4
th
axle line axle centre drive; à p. 7 - 63 16.5 (4.4) M 12
6 or 8 x final drives; à p. 7 - 68 2.7 (0.7) M 12
5 Gear oil Angle gear; à p. 7 - 57 7.7 (2.0) M 6
6 Gear oil
5 x suspension struts;
à p. 7 - 89
1.5 (0.4)
each
M 1
5 x suspension struts; à p. 7 - 89
3.2 (0.84)
each
M 1
7 Gear oil
2 x hoists;
à p. 8 - 11 7 (1.8) each M 12
3 x slewing gears; à p. 8 - 19
0.9 (0.24)
each
M 12
8 Hydraulic oil
Carrier hydraulic tank;
à p. 7 - 111 200 (53) M 12
Superstructure hydraulic tank; à p. 8 - 44 980 (259) M 12
