Manitowoc Grove GMK 5200-1

Spare parts required for maintenance
11.3 Spare parts for the carrier
09.03.2018
Maintenance manual 3 302 746 en 11 - 5
GMK5200-1
11.3 Spare parts for the carrier
Assemblies and spare parts
Carrier
GROVE part
number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Engine
Valve M 20 x 1.5
Gasket 20 x 24 Cu DIN 7603
03041579
Once when the oil is changed
the first time;
recommended modification from
oil drain plug to valve
00117139
Valve M 26 x 1.5
Gasket 26 x 31 Cu DIN 7603
03046878
00117147
Air filter – main filter
Air filter – back-up filter
04161948
1 item when the symbol lights up
04161949
Fuel system
Filter (filter 1; large)
04161567 1
Filter (filter 2; small) 04161566 1
Set of both filters (filter 1 + 2) 04180966 alternatively
Transmission – VIAB
Gasket 24 x 29 Cu DIN 7603
00117145 1
Transmission
Gasket 24 x 29 Cu DIN 7603
00117145 1
Transfer case
Gasket 30 x 36 Cu DIN 7603
00117151 1 1
Gasket 16 x 20 Cu DIN 7603 00117134 1
Angle gear
Gasket 30 x 36 Cu DIN 7603
00117151 1 1
Filter
Packing set
03135866 1
04161645 1
Axle lines axle centre drive (for max. 10 x 8 x 10)
Gasket 30 x 36 Cu DIN 7603
00117151 4 4
Gasket 24 x 29 Cu DIN 7603 00117145 2
Gasket 36 x 42 Cu DIN 7603 01371208 4
Axle lines Final drive (for max. 10 x 8 x 10)
Gasket 24 x 29 Cu DIN 7603
00117145 8 8
