Spare parts required for maintenance
11.2 Lighting
09.03.2018
Maintenance manual 3 302 746 en 11 - 3
GMK5200-1
Red triple light strip for USA:
(at the rear of the chassis)
– Triple light strip 7581100056 LED
White front marker lights:
(at the top on the driver's cab)
– Marker light 03138527 LED
Yellow additional lighting for the USA:
(at the top on the driver's cab)
– Yellow side marker light 03320937 LED
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– LED spotlight; complete 03143786 M 70 LED
– Filament lamp
(for a non-LED spotlight)
02316460 8GH002090-251 70
Yellow rotating beacon:
(on the driver's cab)
– Rotating beacon; complete 04156048
Inside light:
(in the driver's cab)
– Cab light 01207144 R10W 10
– Reading light 00439055 P25-1 21
Dashboard light:
(in the driver's cab; socket 12 V)
– Filament lamp 04159964 Xenon 12 V / 6 W
s
Installation point GROVE part
number
Designation Power (W)
