Spare parts required for maintenance
11.3 Spare parts for the carrier
09.03.2018
Maintenance manual 3 302 746 en 11 - 7
GMK5200-1
Assemblies and spare parts
Carrier
GROVE part
number
Quantity, in single parts
For maintenance interval
Y 2 Y 3 Y 5 Y 6 Y 10
Engine
Oil filter
Cover gasket
04161614 1
03328606 1
Gasket for oil drain plug 04161531 1
Transmission – VIAB
Gasket 24 x 29 Cu DIN 7603
00117145 3
Gasket 14 x 18 Cu DIN 7603 00117131 1
Filter exchange kit 04163770 1
Vent valve filter 04163771 1
Cover gasket filter 04163772 1
Transmission
Filter
03328342 1
Spring 03328343 1
Gasket 03328344 1
Gasket 24 x 29 Cu DIN 7603 00117145 1
