Maintenance overview
5.2 Maintenance plans
5 - 14 3 302 746 en Maintenance manual
GMK5200-1
09.03.2018
5.2.6 Maintenance plan M 12
M 12
Maintenance work on the CARRIER:
every 12 months/after 20,000 - 25,000 km (12,430 - 15,530 mi)
Engine
–Notes; à Engine manufacturer's documentation à p. 7 - 11
– Have the radiator checked/cleaned à p. 7 - 18
– Check V-belt tension à p. 7 - 22
Fuel system
– Replacing fuel filter 2 à p. 7 - 31
Exhaust system with exhaust emission control
– Having the AdBlue system checked à p. 7 - 37
Transmission
– Checking the VIAB oil level à p. 7 - 41
– Checking the transmission oil level à p. 7 - 42
Axle lines
– Axle centre drives – changing the oil à p. 7 - 63
– Final drives – changing the oil à p. 7 - 68
Suspension
– Pressure accumulator – checking the gas pressure à p. 7 - 93
Steering
– Pressure accumulator – checking the gas pressure à p. 7 - 96
Compressed air system
– Replacing the filter cartridge of the compressed air drier à p. 7 - 99
Hydraulic system
– Changing the ventilation filter à p. 7 - 105
– Taking oil samples:
depending on the oil sample test results:
– Changing the hydraulic oil
à p. 7 - 106
à p. 7 - 111
– Changing the hydraulic oil filter à p. 7 - 115
Air conditioning system
– Cleaning the condenser fins à p. 7 - 132
– Checking the entire air conditioning system à p. 7 - 132
– Changing the pollen filter à p. 7 - 134
Other maintenance work
– Lubricating the cab door à p. 7 - 145
– Lubricating the connecting and socket pins à p. 7 - 146
– Renewing the corrosion protection à p. 7 - 147
