MAINTENANCE CD5515-2/YB5515-2 OPERATOR MANUAL
6-8 Published 1-20-2017, Control # 468-02
p0421
Steering Knuckle Lube Points (Rear Axle)
FIGURE 6-7
p0419
Steering Link Lube Points (Front Axle)
FIGURE 6-8
p0422
Steering Link Lube Points (Rear Axle)
FIGURE 6-9
p0418
Steering Cylinder Pivot Ends Lube Points (Front Axle)
FIGURE 6-10
p0420
Steering Cylinder Pivots Ends Lube Points (Rear Axle)
FIGURE 6-11
Reference Only
