MAINTENANCE CD5515-2/YB5515-2 OPERATOR MANUAL
6-28 Published 1-20-2017, Control # 468-02
6. When the tank is empty, disconnect the two hydraulic
lines from the rear of the hydraulic oil tank (Figure 6-48).
Remove the suction strainer from the suction port and
clean it in a suitable solvent.
7. Clean the inside of the hydraulic tank and remove any
sediment.
8. Install the fill strainer, suction strainer, suction hose and
return line to the hydraulic tank.
9. Replace the hydraulic oil filter. See Replace the
Hydraulic Oil Filter, page 6-28.
10. Fill the hydraulic tank with Mobil Fluid 424 hydraulic oil
until level with the sight glass.
11. After the tank is filled, start the engine and operate each
function until all the cylinders and lines are filled.
12. Fully retract and lower the boom and retract the
outriggers. Check the hydraulic oil level. Oil must be
level with the sight glass. Add hydraulic oil if necessary.
13. Visually check for leaks.
Replace the Hydraulic Oil Filter
1. Engage the parking brake and shut off the engine.
NOTE: It is necessary to climb under the crane to replace
the hydraulic oil filter. Be sure engine is shut off, the
ignition key is removed and chock blocks are in
place before climbing under the crane.
2. Locate the hydraulic oil filter under the crane
(Figure 6-49).
3. Remove the filter:
a. Using a filter wrench, turn the filter counterclockwise
to loosen and remove the filter. Properly discard the
removed filter.
b. Clean the mounting surface on the filter head for the
filter.
4. Install the filter:
a. Apply a small amount of clean hydraulic oil to the
gasket of the new hydraulic filter. Install the filter to
the filter head by turning it clockwise until the filter
gasket makes contact. Then, tighten the filter 1/2 to
3/4 turn to achieve a tight seal.
b. Start the engine and check for leaks around the
filter.
Check Swing Gear/Pinion Backlash
1. Remove the cover to expose the swing pinion and ring
gear.
Rotating gears can cause injury. Keep hands clear of rotating
pinion and gear while the mast is rotating. Start the engine
and rotate the mast until the high point on the swing gear is in
alignment with the pinion. The high point is punch-marked on
the mast plate (Figure 6-50).
2. Using a feeler gauge, check the backlash between the
gear and pinion. There should be no clearance between
the swing gear tooth and the pinion tooth. If there is any
clearance, adjust the backlash. See the Service Manual
Section 6, Adjustments.
p0432
Hydraulic Filter
FIGURE 6-49
Reference Only
