Manitowoc National Crane 800D User Manual

National Crane Published 5-27-2018 Control # 039-06 8-1
800D SPECIFICATIONS
SECTION 8
SPECIFICATIONS
(DIMENSIONAL SPECIFICATION)
MAX RATED LOAD MOMENT 4,649,000 lb-in [525 266 Nm] MAX RATED ROTATIONAL TORQUE 405,200 lb-in [45 781 Nm] THRUST @ SLEWING RING @ MAX RATED LOAD MOMENT 12,020 lb [5452 kg] MAXIMUM THRUST 56,750 lb [25 741 kg] THRUST @ SLEWING RING INCLUDES WEIGHTS OF: RATED LOAD, BOOM, LIFT CYLINDER, TURRET
851D 21.0 ft RET - 51 ft EXT [6,40 m - 15,54 m] 860D 24.0 ft RET - 60 ft EXT [7,32 m - 18,29 m] 869D 27.0 ft RET - 69 ft EXT [8,23 m - 21,03 m] 880D 24.5 ft RET - 80 ft EXT [7,47 m - 24,38 m] 890D 27.0 ft RET - 90 ft EXT [8,23 m - 27,43 m]
8100D 29.5 ft RET - 100 ft EXT [8,99 m - 30,48 m]
R43.91 [R1115mm]
TAILSWING
MAINTAIN CLEARANCE
FOR TAILSWING
HOIST
43.12 [1095 mm]
93.30 [2370 mm]
72.02 [1829 mm]
12.35 [314 mm]
18.00 [457 mm]
41.44 [1053 mm]
50.00 [1270 mm]
39.56 [1005 mm]
66.85 [1698 mm]
84.68 [2151 mm]
91.55 [2325 mm]
119.42 [3033 mm]
44.25 [1124 mm]
39.00 [991 mm]
12X ∅1.25 [∅32 mm]
41.88 [1064 mm]
5.25 [133 mm]
2.63 [67 mm]
31.38 [797 mm]
3.81 [97 mm]
47.49 [1206 mm]
43.28 1099 mm]
38.49 [978 mm]
14.56 [370 mm]
48.47 [1231 mm]
40.00 [1016 mm]
GROUND
LEVEL
8.47 [215 mm]
9.00 [229 mm]
18.00 [457 mm]
126.0 [3200 mm]
19.5 [495 mm]
BOTTOM VIEW
SOME COMPONENTS
REMOVED FOR CLARITY
G DRY WEIGHT* W/OIL WEIGHT *
851D 860D 869D 880D 890D 8100D
28 in [71 cm] 46 in [117 cm] 63 in [160 cm] 56 in [142 cm] 68 in [173 cm] 79 in [201 cm]
13,700 lb [6214 kg] 14,270 lb [6472 kg] 14,830 lb [6727 kg] 15,500 lb [7031 kg] 16,465 lb [7468 kg] 17,190 lb [7797 kg]
14,215 lb [6448 kg] 14,790 lb [6709 kg] 15,350 lb [6963 kg] 16,020 lb [7266 kg] 16,985 lb [7704 kg] 17,710 lb [8033 kg]
* - ABOVE WEIGHTS DO NOT INCLUDE SUBBASE, RESERVOIR,
FRONT OR REAR STABILIZERS, JIBS, PTO, PUMP, BED, BOOM
RESTS, REAR BUMPER, OR ANY OTHER MOUNTING OR CRANE
OPTIONS.
SUBBASE WEIGHT C. G.
851D-TM STANDARD 18 ft STANDARD 20 ft STANDARD 22 ft
2500 lb [1134 kg] 2975 lb [1349 kg] 3175 lb [1440 kg] 3445 lb [1563 kg]
*5.75 in [14.6 cm] 108.25 in [275 cm] 120.50 in [306 cm] 143.25 in [364 cm]
SUBBASE C. G. ARE LOCATED FROM THE CENTERLINE OF ROTATION.
*851D-TM C. G. LOCATED ON O/RIG SIDE OF CENTERLINE OF ROTATION.
16 ft [4,87 m] SPAN RSOD 1300 lb [590 kg]
[851D] 14’ [4.26M] SPAM RSOD-TM 1,300 LB. [590 kg]
21.04 [534 mm]
9425
Fo
r
Reference
Only
